2015 International 40hp - E40XMHS (66TX) [140] COMPONER Y PODER VARILLA diagram

1
Yamaha Motors
Power Trim & Tilt Assembly65W-43800-23-8D
Required: 1
ELEVADOR HIDRAULICO COMPL.
Supersedes: 65W-43800-21-4D
$1566.63
You save $276.47

2
Yamaha Motors
Motor Assembly65W-43880-01-00
Required: 1
. MOTOR COMPL.
$370.13
You save $65.32

3
Yamaha Motors
Stator Assembly65W-43804-01-00
Required: 1
. . ESTATOR COMPL
$542.30
You save $95.70

4
Yamaha Motors
Bolt65W-43887-01-00
Required: 2
. . TORNILLO
$11.94
You save $2.11

5
Yamaha Motors
Armature Assembly65W-43805-01-00
Required: 1
. . INDUCIDO COMPL.
$405.49
You save $71.56

6
Yamaha Motors
Washer65W-4387G-00-00
Required: 1
. . ARANDELA
$4.72
You save $0.83

7
Yamaha Motors
End Frame65W-43881-01-00
Required: 1
. . CUADRO EXTERMO
$370.98
You save $65.47

8
Yamaha Motors
Circuit Breaker Comp65W-82181-00-00
Required: 1
. . . RUPTOR DE CIRCUITO COMPL
$102.51
You save $18.09

9
Yamaha Motors
Brush65W-43892-01-00
Required: 1
. . . ESCOBILLA 2
$32.68
You save $5.77

10
Yamaha Motors
Brush65W-43891-01-00
Required: 1
. . . ESCOBILLA 1
$32.68
You save $5.77

11
Yamaha Motors
Brush Spring65W-4386K-01-00
Required: 1
. . . RESORTE, ESCOBILLA
$12.66
You save $2.24

12
Yamaha Motors
Brush Spring65W-4386L-00-00
Required: 1
. . . RESORTE, ESCOBILLA 2
$12.66
You save $2.24
$17.55
You save $3.10

14
Yamaha Motors
With Washer Screw65W-43879-01-00
Required: 2
. . . TORNILLO CON RONDANA
$5.70
You save $1.00

15
Yamaha Motors
Oil Seal65W-43882-01-00
Required: 1
. . . SELLO ACEITE
$27.16
You save $4.79

16
Yamaha Motors
Power Tilt Assembly65W-43840-01-00
Required: 1
. CONJUNTO COMPONER
$853.57
You save $150.63

17
Yamaha Motors
Tilt Cylinder Sub Assembly65W-4380K-00-00
Required: 1
. . CILINDRO, INCLINACION
$347.82
You save $61.38

18
Yamaha Motors
Tilt Piston Sub Assembly65W-43810-01-00
Required: 1
. . ELEVADOR SUB-PISTON COMPL.
$357.09
You save $63.01

19
Yamaha Motors
Rod65W-43801-01-00
Required: 1
. . . VALILLA COMPL INCLINACION
$88.40
You save $15.60

20
Yamaha Motors
Dust Seal65W-43812-00-00
Required: 1
. . . SELLO DE POLVO
In stock
Only 2 remaining
$13.30
You save $2.35

21
Yamaha Motors
O-Ring65W-43865-00-00
Required: 1
. . . ANILLO EN O 5
In stock
Only 1 remaining
$5.31
You save $0.94

22
Yamaha Motors
Cylinder End Screw65W-43811-01-00
Required: 1
. . . TORNILLO CILINDRO EXTREMO
$32.77
You save $5.78

23
Yamaha Motors
O-Ring67C-43867-00-00
Required: 1
. . . ANILLO EN O 7
$4.72
You save $0.83

24
Yamaha Motors
Spring Pin91609-16012-00
Required: 1
. . . PASADOR DE RESORTE
$1.74
You save $0.31

25
Yamaha Motors
Bolt67C-43886-00-00
Required: 1
. . . TORNILLO
$2.38
You save $0.42
In stock
5+ in stock
$0.42
You save $0.08

27
Yamaha Motors
Tilt Piston65W-4385A-01-00
Required: 1
. . . PISTON INCLINACION
$57.08
You save $10.07

28
Yamaha Motors
Absorber Valve Pin65W-4386A-00-00
Required: 5
. . . PASADOR VALVULA ABSORBER
In stock
Only 1 remaining
$5.44
You save $0.96
$2.55
You save $0.45
$1.32
You save $0.23

31
Yamaha Motors
Plate Washer90201-10038-00
Required: 1
. . . ARANDELA PLANA
$5.52
You save $0.97

32
Yamaha Motors
O-Ring6H1-43862-00-00
Required: 1
. . . ANILLO EN O 2
In stock
Only 4 remaining
$11.43
You save $2.02

33
Yamaha Motors
Free Piston Sub Assembly65W-4381B-00-00
Required: 1
. . SUB-PISTON COMPL
$145.09
You save $25.60

34
Yamaha Motors
O-Ring6H1-43861-10-00
Required: 1
. . . ANILLO EN O 1
In stock
5+ in stock
$6.46
You save $1.14

35
Yamaha Motors
O-Ring93210-11368-00
Required: 3
. . ANILLO O
$5.52
You save $0.97

36
Yamaha Motors
Filter69J-4381C-00-00
Required: 1
. . FIELTRO 3
In stock
Only 2 remaining
$7.73
You save $1.37

37
Yamaha Motors
O-Ring93210-06519-00
Required: 4
. . ANILLO O
Supersedes: 93210-064A5-00
In stock
5+ in stock
$3.74
You save $0.66

38
Yamaha Motors
Absorber Valve Pin65W-4386A-00-00
Required: 2
. PASADOR VALVULA ABSORBER
In stock
Only 1 remaining
$5.44
You save $0.96

39
Yamaha Motors
Trim & Tilt Housing65W-4380L-02-00
Required: 1
. CAJA, INCLINACION Y ADRNO
$211.14
You save $37.26
In stock
Only 4 remaining
$5.18
You save $0.92
In stock
Only 1 remaining
$7.22
You save $1.27

42
Yamaha Motors
Valve Sub Assembly67F-43802-01-00
Required: 2
. VALVULA PRINCIPAL COMPL.
Supersedes: 67F-43802-00-00
$108.25
You save $19.10

43
Yamaha Motors
O-Ring6H1-43866-01-00
Required: 1
. . ANILLO EN O 6
In stock
5+ in stock
$2.55
You save $0.45

44
Yamaha Motors
O-Ring93210-12N52-00
Required: 1
. . ANILLO O
In stock
Only 1 remaining
$3.53
You save $0.62
In stock
Only 2 remaining
$3.02
You save $0.53

46
Yamaha Motors
O-RING6AW-43869-09-00
Required: 1
. ANILLO O
Supersedes: 93210-10M74-00
In stock
Only 1 remaining
$4.21
You save $0.74

47
Yamaha Motors
Seat Valve Comp6T4-43808-00-00
Required: 1
. ASIENTO VALVULA COMPLETA 1
$32.09
You save $5.66
$98.81
You save $17.44

49
Yamaha Motors
O-Ring93210-09350-00
Required: 3
. ANILLO O
Supersedes: 93210-09165-00
In stock
Only 4 remaining
$6.37
You save $1.12

50
Yamaha Motors
Shaft Connector65W-43831-00-00
Required: 1
. CONEXION EJE
$8.84
You save $1.56

51
Yamaha Motors
Gear Pump Assembly65W-43830-00-00
Required: 1
. ENGRANAJE BOMBA COMPL.
$328.52
You save $57.98
In stock
5+ in stock
$0.42
You save $0.08
$1.61
You save $0.28
$15.21
You save $2.69
$3.53
You save $0.62
$5.06
You save $0.89
In stock
Only 3 remaining
$6.29
You save $1.11

58
Yamaha Motors
Manual Release Screw6H1-43845-01-00
Required: 1
. TORNILLO DESCOPLO MANUAL
Supersedes: 6H1-43845-00-00
$44.71
You save $7.89

59
Yamaha Motors
O-Ring6D8-43863-00-00
Required: 1
. ANILLO EN O 3
In stock
5+ in stock
$2.42
You save $0.43

60
Yamaha Motors
Manual Valve Seat6H1-43847-00-00
Required: 2
. ASIENTO VALVULA MANUAL
In stock
Only 1 remaining
$7.61
You save $1.34

61
Yamaha Motors
Manual Release Spring65W-43854-00-00
Required: 1
. RESORTE DESCOPLO MANUAL
$5.61
You save $0.99

62
Yamaha Motors
Adaptor65W-4382A-00-00
Required: 1
. ADAPTADOR 1
$12.54
You save $2.21

63
Yamaha Motors
Valve Support Pin65W-43844-00-00
Required: 1
. PASADOR VALVULA SOPORTE
$11.26
You save $1.99

64
Yamaha Motors
Relief Valve Seat65W-43851-00-00
Required: 1
. ASIENTO VALVULA DE DESCARGA
$22.06
You save $3.89

65
Yamaha Motors
O-Ring93210-08003-00
Required: 1
. ANILLO O
Supersedes: 93210-08006-00
In stock
Only 1 remaining
$8.92
You save $1.57

66
Yamaha Motors
O-Ring93210-03494-00
Required: 1
. ANILLO O
Supersedes: 93210-03478-00
In stock
Only 1 remaining
$3.95
You save $0.70

67
Yamaha Motors
Up Relief Spring65W-43855-00-00
Required: 1
. RESORTE SEGURIDAD SUPERIOR
$5.23
You save $0.92
$7.22
You save $1.27
$22.57
You save $3.98

70
Yamaha Motors
Down Relief Spring6H1-43856-10-00
Required: 1
. RESORTE SEGURIDAD
In stock
Only 1 remaining
$5.44
You save $0.96

71
Yamaha Motors
Valve Support Pin6H1-43844-10-00
Required: 1
. PASADOR VALVULA SOPORTE
In stock
Only 1 remaining
$11.35
You save $2.00
In stock
Only 1 remaining
$5.61
You save $0.99
In stock
Only 1 remaining
$0.98
You save $0.17

74
Yamaha Motors
Absorber Valve Spring63P-43857-10-00
Required: 2
. RESORTE
Supersedes: 65W-43853-00-00
$9.44
You save $1.67

75
Yamaha Motors
Reservoir Plug6H1-43829-00-00
Required: 1
. TAPON DEPOSITO
In stock
5+ in stock
$12.54
You save $2.21

76
Yamaha Motors
Socket Bolt62X-43878-01-00
Required: 3
. TORNILLO ENCASTRE
$5.31
You save $0.94
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.



![Yamaha Motors E40XMHS (66TX) [140] - COMPONER Y PODER VARILLA](https://cdn.crowleymarine.com/yamaha/ZBKIuoJr.png)
