1987 Two-Stroke Outboard 55 - DT55 CYLINDER SUPPORT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Suzuki Marine DT55 - CYLINDER SUPPORT
Change View:
Obsolete Suzuki Part
1
Suzuki Marine
Obsolete Suzuki Part48111-95201-0ED
Required: 1
BRACKET, OIL CYLINDER SUPPORT
Supersedes: 48111-95201-02M
Cross Ship
Leaves in 2-5 days
$91.74
$77.98
You save $13.76
More details
Stud Bolt
2
Suzuki Marine
Stud Bolt09108-10061
Required: 2
STUD BOLT
Cross Ship
Leaves in 2-5 days
$9.09
$7.73
You save $1.36
More details
Nut
4
Suzuki Marine
Nut09140-10031
Required: 2
NUT
Cross Ship
Leaves in 2-5 days
$2.45
$1.96
You save $0.49
More details
WASHER
5
Suzuki Marine
WASHER09160-10082
Required: 2
WASHER (10.5X19X2)
Supersedes: 09160-10040
Cross Ship
Leaves in 2-5 days
$1.96
$1.57
You save $0.39
More details
BOLT
6
Suzuki Marine
BOLT09100-10220
Required: 2
BOLT (10X35)
Cross Ship
Leaves in 2-5 days
$9.33
$7.93
You save $1.40
More details
Obsolete Suzuki Part
7
Suzuki Marine
Obsolete Suzuki Part48121-95200
Required: 1
SHAFT, OIL CYLINDER
Cross Ship
Leaves in 2-5 days
$11.63
$9.89
You save $1.74
More details
Obsolete Suzuki Part
8
Suzuki Marine
Obsolete Suzuki Part09160-15036
Required: 2
WASHER (15X30X2)
Cross Ship
Leaves in 2-5 days
$2.50
$2.13
You save $0.38
More details
Obsolete Suzuki Part
10
Suzuki Marine
Obsolete Suzuki Part48163-95200-0ED
Required: 1
SPACER, OIL CYLINDER
Supersedes: 48163-95200-02M
Cross Ship
Leaves in 2-5 days
$23.23
$19.75
You save $3.48
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
