2010 Four-Stroke Outboard 40 - DF40A GEAR CASE diagram
1
Suzuki Marine
CASE,GEAR(BLACK55100-87J50-0EP
Required: 1
CASE ASSY, GEAR
In stock
Only 1 remaining
$861.08
You save $151.96
2
Suzuki Marine
RN 22X30X30 BRG09263-22039
Required: 1
.BEARING, PINION (22X30X30)
$78.34
You save $13.83
3
Suzuki Marine
RT 30X62X17.2509265-30004
Required: 1
.BEARING, PROP SHAFT TAPER RL (30X62X17.25)
$61.45
You save $10.84
In stock
Only 1 remaining
$17.37
You save $3.07
5
Suzuki Marine
BOLT(8X16)09117-08109
Required: 1
BOLT, TRIM TAB (W/WASHER)(8X16)
Supersedes: 09117-08037
$3.20
You save $0.56
6
Suzuki Marine
PLUG,DRAIN,10X709248-10008
Required: 3
PLUG, DRAIN (10X7.5)
In stock
Only 3 remaining
$6.71
You save $1.19
7
Suzuki Marine
GASKET, DRAIN P09168-10022
Required: 3
GASKET, DRAIN PLUG
In stock
5+ in stock
$1.50
You save $0.27
8
Suzuki Marine
BOLT, GEARCASE09116-08131
Required: 6
BOLT, GEAR CASE (W/WASHER)(8X45)
$4.62
You save $0.81
9
Suzuki Marine
Nut09140-08023-XC0
Required: 6
NUT, GEAR CASE (M8)
$2.38
You save $0.42
10
Suzuki Marine
WASHER09160-08082
Required: 6
WASHER, GEAR CASE (8.5X16X1.2
$1.68
You save $0.30
11
Suzuki Marine
9P DF40A/50A/6058100-88LC0-019
Required: 1
PROPELLER (3X11-1/2X9)
Supersedes: 58100-88L01-019
$160.54
You save $28.33
11
Suzuki Marine
10P DF40A/50A/658100-88LD0-019
Required: 1
PROPELLER (3X11-1/2X10)
Supersedes: 58100-88L11-019
$155.52
You save $27.44
11
Suzuki Marine
11P DF40A/50A/658100-88L23-019
Required: 1
PROPELLER (3X11-1/2X11)
Supersedes: 58100-88L21-019
$135.79
You save $23.96
11
Suzuki Marine
12P DF40A/50A/658100-88LA0-019
Required: 1
PROPELLER (3X11-5/8X12)
Supersedes: 58100-88L31-019
$171.08
You save $30.19
11
Suzuki Marine
13P DF40A/50A/658100-88LB0-019
Required: 1
PROPELLER (3X11-1/2X13)
Supersedes: 58100-88L41-019
$160.04
You save $28.24
11
Suzuki Marine
14P DF40A/50A/658100-88LQ0-019
Required: 1
PROPELLER (3X11-3/8X14)
Supersedes: 58100-88L51-019
$145.48
You save $25.67
11
Suzuki Marine
15P DF40A/50A/658100-88LR0-019
Required: 1
PROPELLER (3X11-1/4X15)
Supersedes: 58100-88L61-019
$141.24
You save $24.93
11
Suzuki Marine
16P DF40A/50A/658100-88LS0-019
Required: 1
PROPELLER (3X11-1/8X16)
Supersedes: 58100-88L71-019
$145.48
You save $25.67
11
Required: 1
PROPELLER (3X11X17)
Price unavailable
12
Suzuki Marine
BUSHING, PROP58120-88L01
Required: 1
.BUSH, PROPELLER
Supersedes: 58120-88L00
In stock
Only 2 remaining
$32.07
You save $5.66
13
Suzuki Marine
STOPPER,PROPELL57632-95330
Required: 1
STOPPER, PROPELLER BUSH
Supersedes: 57632-95320
In stock
Only 1 remaining
$41.59
You save $7.34
14
Suzuki Marine
SPACER,PROPELLE57633-94301
Required: 1
SPACER, PROPELLER NUT
Supersedes: 57633-94300
$15.68
You save $2.77
15
Suzuki Marine
NUT 18MM09141-18005
Required: 1
NUT, PROPELLER (M18)
$9.75
You save $1.72
16
Suzuki Marine
COTTER PIN,PROP09204-03003
Required: 1
PIN, COTTER (L:25)
In stock
Only 3 remaining
$2.48
You save $0.44
17
Suzuki Marine
WASHER09160-18028
Required: 1
WASHER, PROP NUT (18.5X31X1)
$3.76
You save $0.66
18
Suzuki Marine
PROP HDWR 40/5557630-94301
Required: 1
KIT, PROPELLER NUT
Supersedes: 57630-94300
$24.94
You save $4.40
19
Suzuki Marine
FLUSH ATTACHMEN55181-95200
Required: 1
ATTACHMENT, FLUSH HOSE
In stock
Only 2 remaining
$6.31
You save $1.11
20
Suzuki Marine
ZINC ASSY PROTE55300-95500
Required: 1
ZINK ASSY, PROTECTION
In stock
Only 2 remaining
$14.93
You save $2.64
21
Suzuki Marine
LU SEALKIT40A5025700-88L03
Required: 1
SEALING KIT, GEAR CASE
Supersedes: 25700-88L00
In stock
Only 4 remaining
$27.15
You save $4.79
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
