2017 International 200hp - F200CA (6DV5) [030] INTAKE 1 diagram

1
Yamaha Motors
BODY, THROTTLE 16DA-13751-02-00
Required: 1
BODY, THROTTLE 1
Supersedes: 6DA-13751-01-00
$1714.28
You save $302.52

2
Yamaha Motors
BOLT, HEXAGON W/W DE97E75-08560-00
Required: 4
BOLT, WITH WASHER
Supersedes: 97575-08560-00
$6.08
You save $1.07
$67.15
You save $11.85

4
Yamaha Motors
DEEP FLANGE BOLT95D75-06025-00
Required: 2
BOLT, FLANGE
Supersedes: 95875-06025-00
$2.93
You save $0.52

5
Yamaha Motors
Intake Silencer Assembly6DA-14440-00-00
Required: 1
SILENCER ASSY, INTAKE
$52.70
You save $9.30

6
Yamaha Motors
DEEP FLANGE BOLT95D75-06025-00
Required: 2
BOLT, FLANGE
Supersedes: 95875-06025-00
$2.93
You save $0.52

7
Yamaha Motors
Silencer Pipe6P2-1441J-01-00
Required: 1
PIPE, SILENCER
Supersedes: 6P2-1441J-00-00
$15.94
You save $2.81
$8.20
You save $1.45

9
Yamaha Motors
Breather Pipe6DA-15373-00-00
Required: 1
PIPE, BREATHER
$62.52
You save $11.03
$2.98
You save $0.52

11
Yamaha Motors
Intake Manifold6DA-13641-00-00
Required: 1
MANIFOLD, INTAKE 1
$307.74
You save $54.31

12
Yamaha Motors
Manifold Gasket6DA-13646-00-00
Required: 1
. GASKET, MANIFOLD 2
$6.21
You save $1.10

13
Yamaha Motors
Manifold Gasket6DA-13645-00-00
Required: 1
. GASKET, MANIFOLD 1
$22.48
You save $3.97

14
Yamaha Motors
Bolt with Washer90119-08020-00
Required: 9
BOLT, WITH WASHER
$4.04
You save $0.71
$167.79
You save $29.61

16
Yamaha Motors
Pan Head Screw97803-05013-00
Required: 2
SCREW, PAN HEAD
Supersedes: 97885-05016-00
In stock
Only 4 remaining
$3.91
You save $0.69

17
Yamaha Motors
Spring Washer92990-05100-00
Required: 2
WASHER
Supersedes: 92995-05100-00
In stock
Only 5 remaining
$0.30
You save $0.05

18
Yamaha Motors
Plate Washer92990-05600-00
Required: 2
WASHER
Supersedes: 92995-05600-00
In stock
Only 4 remaining
$0.68
You save $0.12
$11.47
You save $2.03

20
Yamaha Motors
DEEP FLANGE BOLT95D95-06012-00
Required: 2
BOLT, FLANGE
Supersedes: 95895-06012-00
$0.81
You save $0.14
$4.01
You save $0.71
$2.98
You save $0.52
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.



![Yamaha Motors F200CA (6DV5) [030] - INTAKE 1](https://cdn.crowleymarine.com/yamaha/lqPIkVre.png)
