2017 ATV YXC700E - YXC700E (B85E) [010] EXHAUST diagram
![Yamaha Motors YXC700E (B85E) [010] - EXHAUST](https://cdn.crowleymarine.com/yamaha/WWAXulnR.png)
1
Yamaha Motors
PIPE, EXHAUST 11XD-E4611-02-00
Required: 1
PIPE, EXHAUST 1
Supersedes: 1XD-E4611-01-00
In stock
Only 2 remaining
$125.79
You save $22.20
2
Yamaha Motors
Muffler Gasket1XD-E4714-01-00
Required: 1
GASKET, MUFFLER
In stock
Only 1 remaining
$55.24
You save $9.75
3
Yamaha Motors
Tension Spring90506-26012-00
Required: 2
SPRING, TENSION
$13.17
You save $2.32
4
Yamaha Motors
MUFFLER ASSEMBLY1XD-E4710-01-00
Required: 1
MUFFLER ASSY 1
$424.99
You save $75.00
5
Yamaha Motors
Spark Arrestor Assembly2BG-E4780-00-00
Required: 1
. SPARK ARRESTER ASSY
$64.59
You save $11.40
6
Yamaha Motors
Silencer Gasket2BG-E4755-00-00
Required: 1
. GASKET, SILENCER
$20.39
You save $3.60
7
Yamaha Motors
Flange Bolt95022-06012-00
Required: 4
. BOLT, FLANGE
$3.02
You save $0.53
8
Yamaha Motors
Footrest Damper1HP-F7414-00-00
Required: 1
. DAMPER, FOOTREST
$20.39
You save $3.60
$26.34
You save $4.65
10
Yamaha Motors
Muffler Damper1XD-14737-00-00
Required: 1
DAMPER, MUFFLER
$9.34
You save $1.65
11
Yamaha Motors
Flange Bolt95817-08040-00
Required: 1
BOLT, FLANGE
Supersedes: 95812-08040-00
In stock
Only 2 remaining
$6.37
You save $1.12
$16.99
You save $3.00
In stock
Only 2 remaining
$0.89
You save $0.16
14
Yamaha Motors
EXHAUST PIPE GASKET3EG-14613-00-00
Required: 1
GASKET, EXHAUST PIPE
In stock
Only 1 remaining
$22.09
You save $3.90
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
