All diagrams for this model

Serial Range Four-Stroke Outboard 115 - DF115AZ 610001~ OPT:REMOTE CONTROL (DF115AST E03) diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Suzuki Marine DF115AZ 610001~ - OPT:REMOTE CONTROL (DF115AST E03)
Change View:
ATTACHMENT KIT,
1
Suzuki Marine
ATTACHMENT KIT,67140-95601
Required: 1
KIT, R/CON (NA12S) TWIN
Supersedes: 67140-95600
Cross Ship
Leaves in 2-5 days
$40.90
$34.77
You save $6.13
More details
Spacer
2
Suzuki Marine
Spacer67294-95600
Required: 3
.SPACER
Cross Ship
Leaves in 2-5 days
$5.19
$4.41
You save $0.78
More details
3
Required: 3
.SCREW (L:165)
Price unavailable
MAIN HARNESS 16
4
Suzuki Marine
MAIN HARNESS 1636620-93J54
Required: 1
WIRE ASSY, REMOTE CONTROL
Supersedes: 36620-93J52
Cross Ship
Leaves in 2-5 days
$244.48
$207.81
You save $36.67
More details
MAIN HARNESS 26
4
Suzuki Marine
MAIN HARNESS 2636620-93J64
Required: 1
WIRE ASSY, REMOTE CONTROL
Supersedes: 36620-93J62
Cross Ship
Leaves in 2-5 days
$358.93
$305.09
You save $53.84
More details
Fuse (12V/10A)
5
Suzuki Marine
Fuse (12V/10A)09481-10501
Required: 1
.FUSE (10A)
Cross Ship
Leaves in 2-5 days
$2.50
$2.13
You save $0.38
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
