All diagrams for this model

2016 WaveRunner VX1050D-R - VX1050D-R (F4F2) [010] VENTILATION diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors VX1050D-R (F4F2) [010] - VENTILATION
Change View:
AIR INTAKE BASE
1
Yamaha Motors
AIR INTAKE BASEF2N-U2127-00-00
Required: 2
BASE, AIR INTAKE
Cross Ship
Leaves in 2-5 days
$9.99
$8.49
You save $1.50
More details
VENTILATOR HOSE 2
2
Yamaha Motors
VENTILATOR HOSE 2F2N-U213G-02-00
Required: 2
HOSE, VENTILATOR 2
Supersedes: F2N-U213G-01-00
Cross Ship
Leaves in 2-5 days
$50.99
$43.34
You save $7.65
More details
CLAMP BASE
3
Yamaha Motors
CLAMP BASEF1W-U828M-00-00
Required: 2
BASE, CLAMP
Cross Ship
Leaves in 2-5 days
$5.99
$5.09
You save $0.90
More details
Clamp
5
Yamaha Motors
Clamp90464-99804-00
Required: 2
CLAMP
Cross Ship
Leaves in 2-5 days
$7.99
$6.79
You save $1.20
More details
INDUCTION BOX
6
Yamaha Motors
INDUCTION BOXF2N-U2187-00-00
Required: 1
BOX, INDUCTION 1
Cross Ship
Leaves in 2-5 days
$10.99
$9.34
You save $1.65
More details
Induction Box
7
Yamaha Motors
Induction BoxF2N-U2188-00-00
Required: 1
BOX, INDUCTION 2
Cross Ship
Leaves in 2-5 days
$83.99
$71.39
You save $12.60
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
