2009 Snowmobile RX10STGT - RX10STGT (8GV7) [020] BUMPER diagram

1
Yamaha Motors
Front Bumper8FA-77511-01-00
Required: 1
BUMPER, FRONT 1
$231.19
You save $40.80

2
Yamaha Motors
Flange Bolt95811-08016-00
Required: 4
BOLT, FLANGE
Supersedes: 95812-08016-00
$1.36
You save $0.24

3
Yamaha Motors
Rear Bumper8FG-77541-01-00
Required: 1
BUMPER, REAR 1
$106.24
You save $18.75
$0.26
You save $0.05

5
Yamaha Motors
Rear Bumper8EP-77542-00-00
Required: 1
BUMPER, REAR 2
$62.89
You save $11.10
6
Yamaha Motors
Flange Bolt95817-06016-00
Required: 4
BOLT, FLANGE
Supersedes: 95802-06016-00
$1.66
You save $0.29
7
Yamaha Motors
Spring Nut (4ES)90183-06069-00
Required: 4
NUT, SPRING
Supersedes: 90183-06053-00
In stock
Only 2 remaining
$6.37
You save $1.12
$1.49
You save $0.26

9
Yamaha Motors
Plain Washer 90201-04325-00
Required: 4
WASHER, PLATE
$1.02
You save $0.18

10
Yamaha Motors
Blind Rivet90267-47200-00
Required: 4
RIVET, BLIND (4.7X19.5 BLACK)
In stock
5+ in stock
$2.51
You save $0.44
$95.19
You save $16.80
$124.94
You save $22.05

12
Yamaha Motors
Shroud Lining8FP-77261-00-00
Required: 1
LINING, SHROUD 1
$16.57
You save $2.92
$107.09
You save $18.90
$113.04
You save $19.95

14
Yamaha Motors
SHROUD LINING8FP-77262-00-00
Required: 1
LINING, SHROUD 2
$23.79
You save $4.20

15
Yamaha Motors
Shroud Lining8FP-77263-00-00
Required: 2
LINING, SHROUD 3
$3.27
You save $0.58

16
Yamaha Motors
SIDE PROTECTOR8FR-77561-00-00
Required: 2
PROTECTOR, SIDE 1
$11.47
You save $2.02

17
Yamaha Motors
Binding Screw90154-06009-00
Required: 4
SCREW, BINDING
$3.06
You save $0.54

18
Yamaha Motors
TAIL LIGHT COVER8FP-84516-01-00
Required: 1
COVER, TAILLIGHT
Supersedes: 8FP-84516-00-00
$76.49
You save $13.50
$9.77
You save $1.72
$107.94
You save $19.05

21
Yamaha Motors
BLIND RIVET90267-47187-00
Required: 2
RIVET, BLIND (4.7X16.4 BLACK)
$2.13
You save $0.38
$142.79
You save $25.20

23
Yamaha Motors
Bolt (3JB)91314-06020-00
Required: 6
BOLT, HEXAGON SOCKET HEAD
$2.25
You save $0.40

24
Yamaha Motors
Plain Washer92990-06200-00
Required: 6
WASHER, PLAIN
$0.85
You save $0.15
In stock
5+ in stock
$4.08
You save $0.72

26
Yamaha Motors
TAIL LIGHT BRACKET8FP-2117E-01-00
Required: 1
BRACKET, TAILLIGHT
$17.84
You save $3.15
27
Yamaha Motors
Spring Nut (4ES)90183-06069-00
Required: 2
NUT, SPRING
Supersedes: 90183-06053-00
In stock
Only 2 remaining
$6.37
You save $1.12
$9.77
You save $1.72

29
Yamaha Motors
U Flange Nut95604-06200-00
Required: 2
NUT, SELF-LOCKING
Supersedes: 95602-06200-00
$2.51
You save $0.44
$24.64
You save $4.35
$14.02
You save $2.47
$63.74
You save $11.25
$30.59
You save $5.40
$16.99
You save $3.00
$16.57
You save $2.92
$0.81
You save $0.14
37
Required: 1
FLAP
Price unavailable
$42.49
You save $7.50

38
Yamaha Motors
BRKT. ,FR. FOOD8FP-21979-00-00
Required: 1
BRKT. ,FR. FOOD
$88.39
You save $15.60

39
Yamaha Motors
Flange Bolt95817-06014-00
Required: 4
BOLT, FLANGE
Supersedes: 95822-06014-00
In stock
Only 1 remaining
$2.38
You save $0.42
In stock
Only 1 remaining
$2.21
You save $0.39

41
Yamaha Motors
Front Bracket8FA-21949-00-00
Required: 1
BRACKET, FRONT
$59.49
You save $10.50

42
Yamaha Motors
FRONT BUMPER BRACKET8FA-21959-00-00
Required: 1
BRACKET, FRONT BUMPER
$55.24
You save $9.75

43
Yamaha Motors
95814-08016-0095821-08016-00
Required: 6
BOLT, FLANGE
Supersedes: 95822-08016-00
$1.87
You save $0.33
$31.44
You save $5.55
$1.87
You save $0.33

46
Yamaha Motors
OIL TANK BRACKET8ES-2193E-00-00
Required: 1
BRACKET, OIL TANK 1
$20.39
You save $3.60
$8.07
You save $1.42

48
Yamaha Motors
Cover8FU-2198F-01-00
Required: 1
COVER 1
Supersedes: 8FU-2198F-00-00
$29.74
You save $5.25

49
Yamaha Motors
Cover8FU-2198J-01-00
Required: 1
COVER 3
Supersedes: 8FU-2198J-00-00
$29.74
You save $5.25

50
Yamaha Motors
STEERING BRACKET PLATE8FU-2195E-01-00
Required: 1
PLATE, STRG BRACKET 1
$11.47
You save $2.02

51
Yamaha Motors
STEERING BRACKET PLATE8FU-2195F-01-00
Required: 1
PLATE, STRG BRACKET 2
$11.47
You save $2.02
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.



![Yamaha Motors RX10STGT (8GV7) [020] - BUMPER](https://cdn.crowleymarine.com/yamaha/0wnk5upt.png)
