All diagrams for this model

2003 Snowmobile RX10M - RX10M (8EP2) [020] ALTERNATE (BODY/RIG) diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors RX10M (8EP2) [020] - ALTERNATE (BODY/RIG)
Change View:
Rear View Mirror Kit
1
Yamaha Motors
Rear View Mirror Kit8CR-W2628-00-00
Required: 1
REAR VIEW MIRROR SET
Cross Ship
Leaves in 2-5 days
$199.99
$169.99
You save $30.00
More details
REAR VIEW MIRROR (L)
2
Yamaha Motors
REAR VIEW MIRROR (L)4SV-26280-00-00
Required: 1
. REAR VIEW MIRROR ASSY (LEFT)
Cross Ship
Leaves in 2-5 days
$125.99
$107.09
You save $18.90
More details
Rear View Mirror, Right
3
Yamaha Motors
Rear View Mirror, Right4SV-26290-00-00
Required: 1
. REAR VIEW MIRROR ASSY (RIGHT)
Cross Ship
Leaves in 2-5 days
$137.99
$117.29
You save $20.70
More details
95604-06200-00
4
Yamaha Motors
95604-06200-0095607-06200-00
Required: 4
. NUT, SELF U-FLANGE
Cross Ship
Leaves in 2-5 days
$13.49
$11.47
You save $2.02
More details
Plate Washer
5
Yamaha Motors
Plate Washer90201-06072-00
Required: 4
. WASHER, PLATE
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
