1992 Snowmobile PZ480 - PZ480 (89F1) [020] GENERATOR diagram
![Yamaha Motors PZ480 (89F1) [020] - GENERATOR](https://cdn.crowleymarine.com/yamaha/GfiYV88Q.png)
$560.99
You save $99.00
2
Yamaha Motors
Source Coil86M-85511-00-00
Required: 1
.COIL, source
$119.84
You save $21.15
3
Required: 1
.COIL, lighting 1
Price unavailable
4
Yamaha Motors
Pulser Coil82M-85580-20-00
Required: 1
.COIL, pulser
$147.89
You save $26.10
5
Yamaha Motors
Lead Wire Assembly8W0-85515-20-00
Required: 1
.LEAD WIRE ASSY
$22.09
You save $3.90
6
Required: 2
.CLAMP
Price unavailable
7
Yamaha Motors
.SCREW, PAN HEAD97802-04008-00
Required: 1
.SCREW, pan head
Supersedes: 98580-04008-00
In stock
Only 2 remaining
$1.70
You save $0.30
8
Yamaha Motors
Spring Washer92990-04100-00
Required: 1
.WASHER, spring
Supersedes: 92901-04100-00
In stock
5+ in stock
$0.81
You save $0.14
9
Yamaha Motors
Pan Head Screw98507-05035-00
Required: 2
.SCREW 1
Supersedes: 88T-81145-00-00
$8.07
You save $1.42
10
Yamaha Motors
Pan Head Screw98507-05040-00
Required: 2
.SCREW 2
Supersedes: 88T-81146-00-00
$8.07
You save $1.42
11
Required: 1
.COIL, lighting 2
Price unavailable
$12.74
You save $2.25
13
Yamaha Motors
98507-04018-0098506-04018-00
Required: 2
.SCREW, pan head
$0.68
You save $0.12
14
Yamaha Motors
Spring Washer92990-04100-00
Required: 2
.WASHER, spring
Supersedes: 92901-04100-00
In stock
5+ in stock
$0.81
You save $0.14
$217.59
You save $38.40
$8.07
You save $1.42
17
Yamaha Motors
Plain Washer90201-08043-00
Required: 2
WASHER, plate
In stock
5+ in stock
$7.22
You save $1.27
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
