1991 Snowmobile SV125E - SV125E (88B1) [020] STARTER diagram

1
Yamaha Motors
KICK SHAFT ASSEMBLY87A-15601-00-00
Required: 1
KICK SHAFT ASSY
$73.94
You save $13.05
2
Required: 1
SPRING, torsion
Price unavailable
$1.27
You save $0.23

4
Yamaha Motors
Plate Washer90201-154E9-00
Required: 1
WASHER, plate
$8.92
You save $1.57
$8.07
You save $1.42

6
Yamaha Motors
KICK CRANK ASSEMBLY87A-15620-00-00
Required: 1
KICK CRANK ASSY
$40.79
You save $7.20

7
Yamaha Motors
KICK LEVER COVER156-15618-01-00
Required: 1
.COVER, kick lever
Supersedes: 2T4-15618-00-00
$7.22
You save $1.27

8
Yamaha Motors
Bolt97017-06025-00
Required: 1
BOLT
Supersedes: 97016-06025-00
$3.87
You save $0.68

9
Yamaha Motors
KICK PINION ASSEMBLY87A-15630-00-00
Required: 1
KICK PINION ASSY
$36.54
You save $6.45
$16.57
You save $2.92
$3.82
You save $0.68

12
Yamaha Motors
Starter Wheel50W-15524-00-00
Required: 1
WHEEL, starter
$73.94
You save $13.05

13
Yamaha Motors
BEARING,CYL.#1093310-232J8-00
Required: 1
BEARING, cylindrical
$17.84
You save $3.15
$38.24
You save $6.75

15
Yamaha Motors
Flat Screw98704-06016-00
Required: 3
SCREW, flat head
Supersedes: 98701-06016-00
$4.67
You save $0.82

16
Yamaha Motors
Starter Clutch Assembly4KL-15570-00-00
Required: 1
STARTER CLUTCH ASSY
Supersedes: 50M-15570-01-00
$176.79
You save $31.20
$77.34
You save $13.65

18
Yamaha Motors
Plate Washer90201-087H6-00
Required: 2
WASHER, plate
$2.21
You save $0.39

19
Yamaha Motors
Idle Gear Plate50W-15532-00-00
Required: 1
PLATE, idle gear
$5.52
You save $0.97

20
Yamaha Motors
Screw98517-06012-00
Required: 2
SCREW, pan head
Supersedes: 92501-06012-00
$3.49
You save $0.62
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.



![Yamaha Motors SV125E (88B1) [020] - STARTER](https://cdn.crowleymarine.com/yamaha/J4yALUYV.png)
