1989 Snowmobile SV80 - SV80 (85X1) [010] STARTER diagram

1
Yamaha Motors
KICK SHAFT ASSEMBLY85G-15601-00-00
Required: 1
KICK SHAFT ASSY
$71.39
You save $12.60

2
Yamaha Motors
Torsion Spring90508-32609-00
Required: 1
SPRING, torsion
$14.02
You save $2.47
$1.27
You save $0.23

4
Yamaha Motors
Plate Washer90201-154E9-00
Required: 1
WASHER, plate
$8.92
You save $1.57
$8.07
You save $1.42

6
Yamaha Motors
KICK CRANK ASSEMBLY3KJ-15620-02-00
Required: 1
KICK CRANK ASSY
Supersedes: 27V-15620-00-00
$148.74
You save $26.25

7
Yamaha Motors
KICK LEVER COVER156-15618-01-00
Required: 1
.COVER, kick lever
Supersedes: 2T4-15618-00-00
$7.22
You save $1.27

8
Yamaha Motors
Bolt97017-06025-00
Required: 1
BOLT
Supersedes: 97016-06025-00
$3.87
You save $0.68

9
Yamaha Motors
KICK PINION ASSEMBLY85G-15630-03-00
Required: 1
KICK PINION ASSY
$75.64
You save $13.35

10
Yamaha Motors
SOLID BUSH90380-08201-00
Required: 1
BUSH, solid
Supersedes: 90380-08165-00
$16.57
You save $2.92
$9.34
You save $1.65
$8.07
You save $1.42
$6.37
You save $1.12

14
Yamaha Motors
98707-06014-0098701-06014-00
Required: 2
SCREW, flat head
Supersedes: 92701-06015-00
$0.81
You save $0.14
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
