1989 Snowmobile BR250 - BR250 (86A1) [010] STEERING GATE diagram
![Yamaha Motors BR250 (86A1) [010] - STEERING GATE](https://cdn.crowleymarine.com/yamaha/eDzed6mo.png)
1
Yamaha Motors
Steering Gate83Y-23871-00-00
Required: 1
GATE, steering
$71.39
You save $12.60
2
Yamaha Motors
Flange Bolt95812-06012-00
Required: 4
BOLT, flange
Supersedes: 95811-06012-00
$0.98
You save $0.17
3
Yamaha Motors
Flange Bolt95817-08012-00
Required: 2
BOLT, flange
Supersedes: 95811-08012-00
In stock
Only 1 remaining
$4.67
You save $0.82
4
Yamaha Motors
Knob Holder8F3-21794-00-00
Required: 1
HOLDER, coupler
$7.22
You save $1.27
5
Yamaha Motors
Pan Head Screw98580-06016-00
Required: 2
SCREW, pan head
Supersedes: 92502-06016-00
In stock
Only 5 remaining
$2.85
You save $0.50
6
Yamaha Motors
Spring Washer92995-06100-00
Required: 2
WASHER, spring
Supersedes: 92990-06100-00
In stock
5+ in stock
$2.93
You save $0.52
7
Yamaha Motors
Plain Washer92990-06200-00
Required: 1
WASHER, plain
$0.85
You save $0.15
$6.37
You save $1.12
9
Yamaha Motors
SUCTION PIPE 18A5-14423-00-00
Required: 1
PIPE, suction 1
$11.89
You save $2.10
10
Yamaha Motors
TENSION SPRING90506-06083-00
Required: 1
SPRING, tension
$8.92
You save $1.57
$80.74
You save $14.25
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
