1988 Snowmobile EX570BS8 - EX570BS8 (84N0) [020] TAILLIGHT diagram
![Yamaha Motors EX570BS8 (84N0) [020] - TAILLIGHT](https://cdn.crowleymarine.com/yamaha/OZt6ZlQe.png)
1
Yamaha Motors
TAIL LIGHT UNIT ASSEMBLY82M-84710-01-00
Required: 1
TAILLIGHT UNIT ASSY
Supersedes: 82M-84710-00-00
$37.39
You save $6.60
2
Yamaha Motors
BULB(12V32/3CP)1157137-84714-61-XX
Required: 1
.BULB (12V-23/8W)
Supersedes: 838-84714-01-00
$4.08
You save $0.72
3
Yamaha Motors
Taillight Base82M-84711-01-00
Required: 1
.BASE, taillight
Supersedes: 82M-84711-00-00
$28.04
You save $4.95
4
Yamaha Motors
Taillight Lens8K4-84721-01-00
Required: 1
.LENS, taillight
Supersedes: 8K4-84721-00-00
$40.79
You save $7.20
5
Yamaha Motors
PAN HEAD SCREW97780-40130-00
Required: 4
.SCREW, tapping
$8.07
You save $1.42
6
Yamaha Motors
Lens Gasket3TJ-14457-00-00
Required: 1
.GASKET, tail tens
Supersedes: 8K4-84723-00-00
$19.54
You save $3.45
$2.59
You save $0.46
8
Yamaha Motors
COLLAR90387-060G8-00
Required: 2
COLLAR
Supersedes: 90387-066N1-00
$5.09
You save $0.90
9
Yamaha Motors
Plate Washer90201-06747-00
Required: 4
WASHER, plate
Supersedes: 90201-06407-00
$8.07
You save $1.42
In stock
5+ in stock
$2.25
You save $0.40
11
Yamaha Motors
Spring Washer92995-06100-00
Required: 2
WASHER, spring
Supersedes: 92990-06100-00
In stock
5+ in stock
$2.93
You save $0.52
In stock
5+ in stock
$4.08
You save $0.72
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
