All diagrams for this model

2016 Scooter MW125A - MW125A (2CMS) [020] FRONT BRAKE CALIPER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors MW125A (2CMS) [020] - FRONT BRAKE CALIPER
Change View:
1
Required: 1
DISC, BRAKE 1
Price unavailable
3
Required: 1
PLATE, FITTING
Price unavailable
4
Required: 1
DISC, BRAKE 1
Price unavailable
6
Required: 1
PLATE, FITTING
Price unavailable
7
Required: 1
CALIPER ASSY 2
Price unavailable
8
Required: 1
. PISTON ASSY, CALIPER
Price unavailable
9
Required: 1
. . CALIPER SEAL KIT
Price unavailable
10
Required: 1
. BOOT, CALIPER
Price unavailable
11
Required: 1
. BOOT 2
Price unavailable
13
Required: 1
. SUPPORT, PAD
Price unavailable
14
Required: 1
. PIN, PAD
Price unavailable
15
Required: 1
. RING, STOPPER
Price unavailable
16
Required: 1
. BRACKET, SUPPORT
Price unavailable
17
Required: 1
. PIN BOLT A
Price unavailable
18
Required: 1
. RETAINER BRKT
Price unavailable
19
Required: 1
. NUT
Price unavailable
20
Required: 1
. BOLT
Price unavailable
21
Required: 1
. WASHER, SPRING
Price unavailable
22
Required: 1
. BRAKE PAD KIT
Price unavailable
23
Required: 1
CALIPER ASSY 1
Price unavailable
24
Required: 1
. PISTON ASSY, CALIPER
Price unavailable
25
Required: 1
. . CALIPER SEAL KIT
Price unavailable
26
Required: 1
. BOOT, CALIPER
Price unavailable
27
Required: 1
. BOOT 2
Price unavailable
29
Required: 1
. SUPPORT, PAD
Price unavailable
30
Required: 1
. PIN, PAD
Price unavailable
31
Required: 1
. RING, STOPPER
Price unavailable
32
Required: 1
. BRACKET, SUPPORT
Price unavailable
33
Required: 1
. PIN BOLT A
Price unavailable
34
Required: 1
. RETAINER
Price unavailable
35
Required: 1
. NUT
Price unavailable
36
Required: 1
. BOLT
Price unavailable
37
Required: 1
. WASHER, SPRING
Price unavailable
38
Required: 1
. BRAKE PAD KIT
Price unavailable
39
Required: 4
BOLT, FLANGE
Price unavailable
40
Required: 1
WIRE, HOLDER 1
Price unavailable
41
Required: 1
WIRE, HOLDER 2
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
