All diagrams for this model

2013 Scooter T135SEC - T135SEC (1S9C) [010] SHIFT CAM & FORK diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors T135SEC (1S9C) [010] - SHIFT CAM & FORK
Change View:
1
Required: 1
SHIFT CAM ASSY
Price unavailable
2
Required: 1
SEGMENT
Price unavailable
3
Required: 1
STOPPER
Price unavailable
5
Required: 2
PIN, DOWEL
Price unavailable
6
Required: 1
POINT, NEUTRAL
Price unavailable
Compression Spring
7
Yamaha Motors
Compression Spring90501-06022-00
Required: 1
SPRING, COMPRESSION
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
8
Required: 1
SHIFT LEVER ASSY
Price unavailable
9
Required: 1
BAR, SHIFT FORK GUIDE 1
Price unavailable
Compression Spring
10
Yamaha Motors
Compression Spring90501-06800-00
Required: 2
SPRING, COMPRESSION
Cross Ship
Leaves in 2-5 days
$1.55
$1.32
You save $0.23
More details
11
Required: 1
FORK, SHIFT 1
Price unavailable
12
Required: 1
FORK, SHIFT 2
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
