2012 Scooter AF115S - AF115S (20B8) [010] FRONT WHEEL diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors AF115S (20B8) [010] - FRONT WHEEL
Change View:
1
Required: 1
HUB, FRONT (0035,SL)
Price unavailable
2
Required: 1
SPACER
Price unavailable
Oil Seal
3
Yamaha Motors
Oil Seal93106-20808-00
Required: 1
OIL SEAL
Cross Ship
Leaves in 2-5 days
$1.80
$1.53
You save $0.27
More details
4
Required: 2
BEARING
Price unavailable
5
Required: 1
SPOKE SET, FRONT
Price unavailable
6
Required: 1
TIRE (70/90-14 M/C 34P NF59)
Price unavailable
6
Required: 1
TIRE (70/90-14 M/C 34P V282F)
Price unavailable
7
Required: 1
TUBE (70/90-14 TR-4)
Price unavailable
7
Required: 1
TUBE (70/90-14 TR-4)
Price unavailable
8
Required: 1
BAND, RIM (22-14)
Price unavailable
8
Required: 1
BAND, RIM (70-80/90-14)
Price unavailable
9
Required: 1
RIM (1.40-14)
Price unavailable
10
Required: 1
COLLAR
Price unavailable
517 F. WHEEL COLLAR
11
Yamaha Motors
517 F. WHEEL COLLAR90387-10277-00
Required: 1
COLLAR
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details
12
Required: 1
AXLE, WHEEL
Price unavailable
13
Required: 1
NUT, SELF-LOCKING
Price unavailable
Plain Washer
14
Yamaha Motors
Plain Washer90201-101J1-00
Required: 1
WASHER, PLATE
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
15
Required: 1
GEAR UNIT ASSY
Price unavailable
