2012 Scooter AF115C - AF115C (1UB2) [010] EXHAUST diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors AF115C (1UB2) [010] - EXHAUST
Change View:
1
Required: 1
EXHAUST PIPE ASSY 1
Price unavailable
2
Required: 1
PROTECTOR, MUFFLER 1
Price unavailable
BOLT
3
Yamaha Motors
BOLT90111-06015-00
Required: 2
BOLT,HEX. SOCKET BUTTON
Supersedes: 90111-06807-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
4
Required: 1
STAY, MUFFLER 1
Price unavailable
Flange Bolt
5
Yamaha Motors
Flange Bolt95817-10035-00
Required: 1
BOLT, FLANGE
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
SELF-LOCKING NUT
8
Yamaha Motors
SELF-LOCKING NUT90185-08017-00
Required: 1
NUT, SELF-LOCKING
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
Washer Plate 8AT
9
Yamaha Motors
Washer Plate 8AT90201-081R9-00
Required: 1
WASHER, PLATE
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details
10
Required: 1
DAMPER, MUFFLER
Price unavailable
11
Required: 1
COLLAR 1
Price unavailable
GROMMET, WATER TUBE (UPPER)
13
Yamaha Motors
GROMMET, WATER TUBE (UPPER)90480-10017-00
Required: 1
GROMMET
Supersedes: 90480-10332-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
14
Required: 1
GASKET, EXHAUST PIPE
Price unavailable
Flange Nut
15
Yamaha Motors
Flange Nut95707-08500-00
Required: 2
NUT, FLANGE
Cross Ship
Leaves in 2-5 days
$1.95
$1.82
You save $0.13
More details
BOLT
16
Yamaha Motors
BOLT91317-08035-00
Required: 2
BOLT
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
18
Required: 1
GASKET, MUFFLER
Price unavailable
19
Required: 1
PIPE 2
Price unavailable
20
Required: 1
HOSE, BEND 1
Price unavailable
21
Required: 2
CLIP
Price unavailable
24
Required: 1
AIR INDUCTION SYSTEM ASSY
Price unavailable
25
Required: 1
HOSE 1
Price unavailable
26
Required: 1
HOSE, VACUUM SENSING 1
Price unavailable
27
Required: 1
CLIP
Price unavailable
Scissor Clip
28
Yamaha Motors
Scissor Clip90467-08021-00
Required: 3
CLIP
Supersedes: 90467-08075-00
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
29
Required: 1
HOSE, AIR
Price unavailable
Grommet
30
Yamaha Motors
Grommet90480-13M24-00
Required: 2
GROMMET
Cross Ship
Leaves in 2-5 days
$9.05
$7.24
You save $1.81
More details
Way
31
Yamaha Motors
Way90413-05014-00
Required: 1
WAY 3
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
