2007 Scooter XC125 - XC125 (4P92) [030] HEADLIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XC125 (4P92) [030] - HEADLIGHT
Change View:
1
Required: 1
HEADLIGHT UNIT ASSY
Price unavailable
2
Required: 1
. HEADLIGHT UNIT ASSY
Price unavailable
Headlight Bulb
3
Yamaha Motors
Headlight Bulb1B6-H4314-00-00
Required: 1
. BULB, HEADLIGHT (12V-60/55W)
Cross Ship
Leaves in 2-5 days
$26.99
$22.94
You save $4.05
More details
BULB (12V-5W)
4
Yamaha Motors
BULB (12V-5W)5FM-H4347-00-00
Required: 2
. BULB (12V-5W)
Cross Ship
Leaves in 2-5 days
$33.99
$28.89
You save $5.10
More details
5
Required: 1
. SOCKET CORD ASSY 1
Price unavailable
6
Required: 1
. COVER
Price unavailable
Tapping Screw
7
Yamaha Motors
Tapping Screw97707-60020-00
Required: 4
SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$0.55
$0.47
You save $0.08
More details
Spring Nut
8
Yamaha Motors
Spring Nut90183-06801-00
Required: 1
NUT, SPRING
Cross Ship
Leaves in 2-5 days
$1.50
$1.27
You save $0.23
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
