2002 Scooter XN150 - XN150 (5PR3) [010] ELECTRICAL 1 diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XN150 (5PR3) [010] - ELECTRICAL 1
Change View:
1
Required: 1
C.D.I. UNIT ASSY
Price unavailable
2
Required: 1
BAND
Price unavailable
3
Required: 1
RECTIFIER & REGULATOR ASSY
Price unavailable
4
Required: 2
SCREW, BINDING
Price unavailable
5
Required: 1
SENDER, WATER
Price unavailable
6
Required: 1
IGNITION COIL ASSY
Price unavailable
Hexagon Screw
7
Yamaha Motors
Hexagon Screw90153-06034-00
Required: 1
SCREW, HEXAGON
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
8
Required: 1
BOLT, WASHER BASED
Price unavailable
9
Required: 1
PLUG CAP ASSY
Price unavailable
10
Required: 1
THERMO SWITCH ASSY
Price unavailable
Starter Relay Assembly
11
Yamaha Motors
Starter Relay Assembly3MW-81940-01-00
Required: 1
STARTER RELAY ASSY
Supersedes: 3MW-81940-00-00
Cross Ship
Leaves in 2-5 days
$89.99
$76.49
You save $13.50
More details
12
Required: 2
BOLT, SPECIAL
Price unavailable
WASHER, TOOTH
13
Yamaha Motors
WASHER, TOOTH90205-06X00-00
Required: 2
WASHER, TOOTH
Cross Ship
Leaves in 2-5 days
$0.99
$0.84
You save $0.15
More details
14
Required: 1
CORD, STARTER MOTOR
Price unavailable
15
Required: 1
BOLT, WITH WASHER
Price unavailable
Horn
16
Yamaha Motors
Horn2KG-83371-00-00
Required: 1
HORN
Cross Ship
Leaves in 2-5 days
$93.99
$79.89
You save $14.10
More details
17
Required: 1
SCREW, BINDING
Price unavailable
18
Required: 1
SENDER UNIT ASSY, FUEL METER
Price unavailable
19
Required: 1
. GASKET, SENDER UNIT
Price unavailable
20
Required: 1
HOUSING, FUEL METER
Price unavailable
21
Required: 1
THERMO SWITCH ASSY
Price unavailable
22
Required: 1
THERMO SWITCH ASSY
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
