2001 Scooter CW50RS - CW50RS (5FXM) [040] FRONT WHEEL diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors CW50RS (5FXM) [040] - FRONT WHEEL
Change View:
1
Required: 1
CAST WHEEL, FRONT
Price unavailable
BEARING SPACER
2
Yamaha Motors
BEARING SPACER4SB-F5117-00-00
Required: 1
. SPACER, BEARING
Cross Ship
Leaves in 2-5 days
$12.99
$11.04
You save $1.95
More details
3
Required: 2
. BEARING
Price unavailable
4
Required: 1
COLLAR
Price unavailable
DD-Type Oil Seal
5
Yamaha Motors
DD-Type Oil Seal93106-20001-00
Required: 1
OIL SEAL
Cross Ship
Leaves in 2-5 days
$2.50
$2.13
You save $0.38
More details
6
Required: 1
TIRE MICHELIN 120/90-10
Price unavailable
7
Required: 1
AIR VALVE ASSY
Price unavailable
9
Required: 1
SHAFT, PIVOT
Price unavailable
Gear Unit Assembly
10
Yamaha Motors
Gear Unit Assembly4YB-F5190-01-00
Required: 1
GEAR UNIT ASSY
Supersedes: 4YB-F5190-00-00
Cross Ship
Leaves in 2-5 days
$59.99
$50.99
You save $9.00
More details
METER GEAR
11
Yamaha Motors
METER GEAR4YB-F5138-00-00
Required: 1
. GEAR, METER
Cross Ship
Leaves in 2-5 days
$17.49
$14.87
You save $2.62
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
