2000 Scooter YQ50L - YQ50L (5KH7) [010] GENERATOR diagram
![Yamaha Motors YQ50L (5KH7) [010] - GENERATOR](https://cdn.crowleymarine.com/yamaha/p2uQdC66.png)
1
Yamaha Motors
Rotor Assembly2JA-85550-02-00
Required: 1
ROTOR ASSY
Supersedes: 2JA-85550-00-00
$158.94
You save $28.05
$192.09
You save $33.90
3
Required: 1
. STATORCOMP.
Price unavailable
4
Yamaha Motors
Pulser Coil2JA-85580-M0-00
Required: 1
. COIL, PULSER
$63.74
You save $11.25
$8.07
You save $1.42
6
Yamaha Motors
Pan Head Screw98517-05020-00
Required: 2
. SCREW, PAN HEAD
Supersedes: 98507-05020-00
$1.49
You save $0.26
7
Yamaha Motors
PAN HEAD SCREW (3SX)98517-05010-00
Required: 2
. SCREW, PAN HEAD
In stock
Only 4 remaining
$3.91
You save $0.69
8
Yamaha Motors
Pan Head Screw98517-04006-00
Required: 1
. SCREW, PAN HEAD
$3.82
You save $0.68
9
Yamaha Motors
Spring Washer92990-04100-00
Required: 1
. WASHER, SPRING
In stock
5+ in stock
$0.81
You save $0.14
10
Yamaha Motors
Pan Head Screw98507-06016-00
Required: 2
SCREW, PAN HEAD
$2.96
You save $0.52
11
Yamaha Motors
Plate Washer92990-10600-00
Required: 1
WASHER, PLATE
In stock
5+ in stock
$2.55
You save $0.45
12
Yamaha Motors
Nut90170-10011-00
Required: 1
NUT
Supersedes: 90170-10219-00
$7.22
You save $1.27
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
