2000 Scooter YN50 - YN50 (5BV5) [010] SEAT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YN50 (5BV5) [010] - SEAT
Change View:
1
Required: 1
DOUBLE SEAT ASSY
Price unavailable
2
Required: 1
. SEAL
Price unavailable
3
Required: 1
. LABEL, CAUTION
Price unavailable
4
Required: 1
. SUPPORT, SPRING 1
Price unavailable
5
Required: 1
. SPRING
Price unavailable
6
Required: 1
BOX 1
Price unavailable
7
Required: 4
BOLT
Price unavailable
SPECIAL SHAPE NUT
8
Yamaha Motors
SPECIAL SHAPE NUT90179-06403-00
Required: 2
NUT
Cross Ship
Leaves in 2-5 days
$6.99
$5.94
You save $1.05
More details
9
Required: 1
HINGE, SEAT
Price unavailable
10
Required: 1
PIN, SEAT FITTING
Price unavailable
SPECIAL SHAPE NUT
11
Yamaha Motors
SPECIAL SHAPE NUT90179-06403-00
Required: 2
NUT
Cross Ship
Leaves in 2-5 days
$6.99
$5.94
You save $1.05
More details
12
Required: 2
HANDLE, STANDING
Price unavailable
13
Required: 4
BOLT, HEXAGON SOCKET HEAD
Price unavailable
14
Required: 1
CAP, BOLT
Price unavailable
15
Required: 1
TOOL KIT
Price unavailable
16
Required: 1
HOLDER, TOOL
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
