2000 Scooter YN50 - YN50 (5ADW) [010] OIL PUMP diagram
1
Required: 1
OIL PUMP ASSY
Price unavailable

2
Yamaha Motors
Breather Bolt3WF-13185-00-00
Required: 1
. BOLT, BREATHER
Supersedes: 1YU-13185-00-00
$7.22
You save $1.27

3
Yamaha Motors
Breather Bolt Gasket1YU-13187-00-00
Required: 1
. GASKET, BREATHER BOLT
$7.22
You save $1.27
$7.22
You save $1.27

5
Yamaha Motors
WORM GEAR WHEEL3AA-13124-00-00
Required: 1
. GEAR, WORM WHEEL
$8.92
You save $1.57
$7.22
You save $1.27
$3.10
You save $0.55

8
Yamaha Motors
Hose90445-092K1-00
Required: 1
. HOSE
Supersedes: 90445-09252-00
In stock
5+ in stock
$10.62
You save $1.87
$9.77
You save $1.72
10
Yamaha Motors
Hose90445-055E5-00
Required: 1
. HOSE
Supersedes: 90445-052G4-00
$8.92
You save $1.57
$8.07
You save $1.42
12
Required: 1
CLIP
Price unavailable

13
Yamaha Motors
Pan Head Screw98507-05014-00
Required: 2
SCREW, PAN HEAD
$8.07
You save $1.42

14
Yamaha Motors
Pump Drive Gear3VL-E3178-00-00
Required: 1
GEAR, PUMP DRIVE
$25.49
You save $4.50
$2.34
You save $0.41
$8.07
You save $1.42
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
