2001 Scooter XC125A - XC125A (5MJ3) [010] FRONT WHEEL diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XC125A (5MJ3) [010] - FRONT WHEEL
Change View:
1
Required: 1
CAST WHEEL, FRONT
Price unavailable
2
Required: 1
COLLAR, WHEEL
Price unavailable
Oil Seal
3
Yamaha Motors
Oil Seal93102-17853-00
Required: 1
OIL SEAL
Cross Ship
Leaves in 2-5 days
$0.90
$0.76
You save $0.14
More details
BEARING
5
Yamaha Motors
BEARING93306-201X2-00
Required: 1
BEARING
Supersedes: 93306-201Y2-00
Cross Ship
Leaves in 2-5 days
$4.85
$8.91
You save $-4.06
More details
Rim Valve
6
Yamaha Motors
Rim Valve93900-00802-00
Required: 1
VALVE, RIM
Cross Ship
Leaves in 2-5 days
$6.49
$5.52
You save $0.97
More details
7
Required: 1
TIRE
Price unavailable
FLANGE NUT
8
Yamaha Motors
FLANGE NUT95607-12200-00
Required: 1
NUT, SELF-LOCKING
Cross Ship
Leaves in 2-5 days
$6.49
$5.52
You save $0.97
More details
9
Required: 1
AXLE, WHEEL
Price unavailable
COLLAR
10
Yamaha Motors
COLLAR90387-12852-00
Required: 1
COLLAR
Supersedes: 90387-125J1-00
Cross Ship
Leaves in 2-5 days
$4.05
$3.44
You save $0.61
More details
11
Required: 1
GEAR UNIT ASSY
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
