1997 Scooter YP250 - YP250 (4UC2) [080] METER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YP250 (4UC2) [080] - METER
Change View:
1
Required: 1
SPEEDOMETER ASSY
Price unavailable
1
Required: 1
SPEEDOMETER ASSY
Price unavailable
2
Required: 1
. SPEEDOMETER ASSY
Price unavailable
2
Required: 1
. SPEEDOMETER ASSY
Price unavailable
3
Required: 1
. FUEL METER ASSY
Price unavailable
4
Required: 1
. WATER TEMPERATURE ASSY
Price unavailable
5
Required: 1
. LENS, SPEEDOMETER
Price unavailable
6
Required: 1
. COVER, METER PANEL
Price unavailable
7
Required: 1
. CASE, UNDER
Price unavailable
8
Required: 1
. DIGITAL CLOCK ASSY
Price unavailable
9
Required: 2
. PLUG, BLIND
Price unavailable
10
Required: 1
. SOCKET CORD ASSY
Price unavailable
Obsolete Yamaha Part
11
Yamaha Motors
Obsolete Yamaha Part3GM-83517-00-00
Required: 6
. BULB
Supersedes: 1YT-83517-00-00
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
Tapping Screw
12
Yamaha Motors
Tapping Screw97707-30512-00
Required: 4
. SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$1.55
$1.32
You save $0.23
More details
Screw with Washer
13
Yamaha Motors
Screw with Washer90159-03102-00
Required: 6
. SCREW, WITH WASHER
Cross Ship
Leaves in 2-5 days
$2.30
$1.96
You save $0.35
More details
Tapping Screw
14
Yamaha Motors
Tapping Screw90167-04021-00
Required: 2
. SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$2.30
$1.96
You save $0.35
More details
Tapping Screw
15
Yamaha Motors
Tapping Screw97707-40016-00
Required: 4
. SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
Tapping Screw
16
Yamaha Motors
Tapping Screw97707-40014-00
Required: 1
. SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
17
Required: 1
. SWITCH
Price unavailable
4G1-84744-00-XX
18
Yamaha Motors
4G1-84744-00-XX4G1-84744-00-00
Required: 2
. BULB
Supersedes: 4R0-83517-00-00
Cross Ship
Leaves in 2-5 days
$5.99
$5.09
You save $0.90
More details
20
Required: 1
SPEEDOMETER CABLE ASSY
Price unavailable
21
Required: 2
LOCK 1
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
