1992 Scooter CY50 - CY50 (3SA3) [010] FENDER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors CY50 (3SA3) [010] - FENDER
Change View:
1
Required: 1
FENDER, front
Price unavailable
2
Required: 1
EMBLEM
Price unavailable
3
Required: 1
EMBLEM
Price unavailable
FENDER,INNER
4
Yamaha Motors
FENDER,INNER3KJ-21552-03-00
Required: 1
FENDER, inner
Supersedes: 3KJ-21552-00-00
Cross Ship
Leaves in 2-5 days
$42.99
$36.54
You save $6.45
More details
INNER FENDER
5
Yamaha Motors
INNER FENDER27V-21553-03-00
Required: 1
FENDER, inner 2
Cross Ship
Leaves in 2-5 days
$7.99
$6.79
You save $1.20
More details
Screw With Washer
6
Yamaha Motors
Screw With Washer90159-06178-00
Required: 3
SCREW, with washer
Supersedes: 90159-06124-00
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
Bolt With Washer
9
Yamaha Motors
Bolt With Washer90119-06123-00
Required: 2
BOLT, with washer
Supersedes: 90119-06085-00
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
Truss Screw
10
Yamaha Motors
Truss Screw97707-50012-00
Required: 2
SCREW, tapping
Supersedes: 90167-05041-00
Cross Ship
Leaves in 2-5 days
$4.63
$3.94
You save $0.69
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
