1998 Maxi-Scooter STR126A - STR126A (5BD1) [010] CRANKCASE diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors STR126A (5BD1) [010] - CRANKCASE
Change View:
1
Required: 1
CRANKCASE 1
Price unavailable
2
Required: 1
CRANKCASE 2
Price unavailable
2
Required: 1
CRANKCASE 2
Price unavailable
4
Required: 2
BOLT, STUD
Price unavailable
5
Required: 2
BOLT, STUD
Price unavailable
6
Required: 3
SCREW, PAN HEAD
Price unavailable
7
Required: 5
SCREW, PAN HEAD
Price unavailable
8
Required: 6
SCREW, PAN HEAD
Price unavailable
9
Required: 1
COVER
Price unavailable
10
Required: 2
SCREW, PAN HEAD
Price unavailable
11
Required: 1
PLATE
Price unavailable
12
Required: 1
SCREW, PAN HEAD
Price unavailable
13
Required: 1
CONNECTOR, SUCTION PIPE
Price unavailable
90445-08336-00
14
Yamaha Motors
90445-08336-0090445-086A8-00
Required: 1
HOSE
Supersedes: 90445-08605-00
Cross Ship
Leaves in 2-5 days
$10.99
$9.34
You save $1.65
More details
15
Required: 1
CLAMP 2
Price unavailable

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
