All diagrams for this model

2015 International RIGGING - RIGGING REMOCON-2015 (601R) [010] SWITCH & PANEL 7 diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors RIGGING REMOCON-2015 (601R) [010] - SWITCH & PANEL 7
Change View:
PANEL SWITCH ASSY
1
Yamaha Motors
PANEL SWITCH ASSY61B-82570-08-00
Required: 1
PANEL SWITCH ASSY
Supersedes: 61B-82570-06-00
Cross Ship
Leaves in 2-5 days
$920.00
$782.00
You save $138.00
More details
Panel Switch Plate
2
Yamaha Motors
Panel Switch Plate6K1-82571-02-00
Required: 1
. PLATE, PANEL SWITCH
Cross Ship
Leaves in 2-5 days
$94.50
$80.33
You save $14.17
More details
..PLATE
3
Yamaha Motors
..PLATE61B-82588-01-00
Required: 1
. . PLATE
Cross Ship
Leaves in 2-5 days
$53.30
$45.30
You save $8.00
More details
Main Switch Assembly TE, TP
4
Yamaha Motors
Main Switch Assembly TE, TP61B-82510-03-00
Required: 2
. MAIN SWITCH ASSY
Supersedes: 61B-82510-02-00
Cross Ship
Leaves in 2-5 days
$172.50
$146.63
You save $25.88
More details
Engine Stop Switch Assembly
7
Yamaha Motors
Engine Stop Switch Assembly6K1-82575-01-00
Required: 1
. ENGINE STOP SWITCH ASSY
Cross Ship
Leaves in 2-5 days
$85.60
$72.76
You save $12.84
More details
Bracket
9
Yamaha Motors
Bracket6K1-83614-01-00
Required: 1
. BRACKET
Cross Ship
Leaves in 2-5 days
$27.25
$23.16
You save $4.09
More details
Bind Screw
10
Yamaha Motors
Bind Screw98980-05010-00
Required: 2
. SCREW, BIND
Cross Ship
Leaves in 2-5 days
$2.55
$2.17
You save $0.38
More details
Buzzer
13
Yamaha Motors
Buzzer6R5-83383-00-00
Required: 2
. BUZZER
Cross Ship
Leaves in 2-5 days
$56.25
$47.81
You save $8.44
More details
CONTROL UNIT ASSEMBLY
14
Yamaha Motors
CONTROL UNIT ASSEMBLY61B-85830-01-00
Required: 1
. CONTROL UNIT ASSY
Cross Ship
Leaves in 2-5 days
$533.60
$453.56
You save $80.04
More details
Bind Screw
15
Yamaha Motors
Bind Screw98980-06020-00
Required: 2
. SCREW, BIND
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
