2014 International 225hp - F225FET (6CL5) [070] LAYOUT CHART 1 (SINGLE) diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors F225FET (6CL5) [070] - LAYOUT CHART 1 (SINGLE)
Change View:
1
Required: 1
REMOTE CONTROL ASSY (SINGLE)
Price unavailable
Panel Switch Assembly
2
Yamaha Motors
Panel Switch Assembly6X6-82570-30-00
Required: 1
PANEL SWITCH ASSY
Supersedes: 6X6-82570-31-00
Cross Ship
Leaves in 2-5 days
$281.00
$238.85
You save $42.15
More details
Panel Switch Assembly
3
Yamaha Motors
Panel Switch Assembly6X6-82570-80-00
Required: 1
PANEL SWITCH ASSY
Cross Ship
Leaves in 2-5 days
$314.00
$266.90
You save $47.10
More details
Panel Switch Assembly
4
Yamaha Motors
Panel Switch Assembly6X6-82570-90-00
Required: 1
PANEL SWITCH ASSY
Cross Ship
Leaves in 2-5 days
$293.00
$249.05
You save $43.95
More details
Panel Switch Assembly
5
Yamaha Motors
Panel Switch Assembly6X6-82570-B0-00
Required: 2
PANEL SWITCH ASSY
Cross Ship
Leaves in 2-5 days
$250.00
$212.50
You save $37.50
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
