2018 Cruiser XV1900CFD - XV1900CFD (2DG6) [010] METER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XV1900CFD (2DG6) [010] - METER
Change View:
1
Required: 1
METER ASSY
Price unavailable
UPPER CASE
2
Yamaha Motors
UPPER CASE2DF-8353G-00-00
Required: 1
. CASE, UPPER
Cross Ship
Leaves in 2-5 days
$101.99
$86.69
You save $15.30
More details
UPPER CASE
3
Yamaha Motors
UPPER CASE2DF-8353G-10-00
Required: 1
. CASE, UPPER
Cross Ship
Leaves in 2-5 days
$99.99
$84.99
You save $15.00
More details
Tapping Screw
4
Yamaha Motors
Tapping Screw4AS-83616-10-00
Required: 18
. SCREW, TAPPING
Cross Ship
Leaves in 2-5 days
$2.90
$2.46
You save $0.44
More details
Tuning Fork Mark
5
Yamaha Motors
Tuning Fork Mark5GT-2836B-10-00
Required: 1
. TUNING FORK MARK
Supersedes: 5GT-2836B-00-00
Cross Ship
Leaves in 2-5 days
$17.99
$15.29
You save $2.70
More details
Spring Nut
6
Yamaha Motors
Spring Nut90183-050A6-00
Required: 2
NUT, SPRING
Supersedes: 90183-05076-00
Cross Ship
Leaves in 2-5 days
$2.95
$2.51
You save $0.44
More details
Plate Washer
8
Yamaha Motors
Plate Washer90201-06085-00
Required: 3
WASHER, PLATE
Cross Ship
Leaves in 2-5 days
$3.25
$2.76
You save $0.49
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
