2013 Cruiser VMX17 - VMX17 (2CE3) [010] HANDLE SWITCH & LEVER diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors VMX17 (2CE3) [010] - HANDLE SWITCH & LEVER
Change View:
Handle Switch
1
Yamaha Motors
Handle Switch2S3-83972-01-00
Required: 1
SWITCH, HANDLE 4
Supersedes: 2S3-83972-00-00
Cross Ship
Leaves in 2-5 days
$122.99
$104.54
You save $18.45
More details
Pan Head Screw
2
Yamaha Motors
Pan Head Screw98517-05030-00
Required: 1
. SCREW, PAN HEAD
Supersedes: 98507-05030-00
Cross Ship
Leaves in 2-5 days
$11.49
$9.77
You save $1.72
More details
Pan Head Screw
3
Yamaha Motors
Pan Head Screw98507-05045-00
Required: 1
. SCREW, PAN HEAD
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details
Handle Switch
4
Yamaha Motors
Handle Switch2S3-83975-00-00
Required: 1
SWITCH, HANDLE 2
Cross Ship
Leaves in 2-5 days
$96.99
$82.44
You save $14.55
More details
PAN HEAD SCREW
5
Yamaha Motors
PAN HEAD SCREW90157-05057-00
Required: 2
. SCREW, PAN HEAD
Supersedes: 98507-05022-00
Cross Ship
Leaves in 2-5 days
$3.85
$3.27
You save $0.58
More details
Plug
6
Yamaha Motors
Plug90338-06007-00
Required: 1
PLUG
Cross Ship
Leaves in 2-5 days
$10.49
$8.92
You save $1.57
More details
CABLE GUIDE
7
Yamaha Motors
CABLE GUIDE2S3-2331E-00-00
Required: 1
GUIDE, CABLE
Cross Ship
Leaves in 2-5 days
$11.49
$9.77
You save $1.72
More details
Clamp
8
Yamaha Motors
Clamp90464-14009-00
Required: 1
CLAMP
Cross Ship
Leaves in 2-5 days
$4.40
$3.74
You save $0.66
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
