2002 Cruiser XVS250 - XVS250 (5KR5) [040] OIL PUMP diagram
![Yamaha Motors XVS250 (5KR5) [040] - OIL PUMP](https://cdn.crowleymarine.com/yamaha/cs1VhcUB.png)
1
Yamaha Motors
Oil Pump Assembly2UJ-13300-10-00
Required: 1
OIL PUMP ASSY
Supersedes: 2UJ-13300-00-00
$152.14
You save $26.85
2
Yamaha Motors
Pump Drive Gear3Y6-13326-01-00
Required: 1
. GEAR, PUMP DRIVEN 2 (23T)
$17.84
You save $3.15
3
Yamaha Motors
Dowel Pin93603-12030-00
Required: 1
. PIN, DOWEL
In stock
Only 5 remaining
$2.38
You save $0.42
In stock
Only 3 remaining
$3.44
You save $0.61
5
Yamaha Motors
Pan Head Screw98517-06025-00
Required: 2
SCREW, PAN HEAD
Supersedes: 98507-06025-00
$3.44
You save $0.61
$5.52
You save $0.97
7
Yamaha Motors
Flat Screw98707-06025-00
Required: 1
SCREW, FLAT HEAD
$8.07
You save $1.42
8
Yamaha Motors
OIL PUMP IDLE GEAR2UJ-13341-00-00
Required: 1
GEAR, OIL PUMP IDLE
$35.69
You save $6.30
9
Yamaha Motors
Plate Washer90201-10119-00
Required: 2
WASHER, PLATE
In stock
Only 2 remaining
$0.85
You save $0.15
$4.67
You save $0.82
11
Yamaha Motors
Oil Pipe 12XK-13416-00-00
Required: 1
PIPE, OIL 1
Supersedes: 3Y1-13416-01-00
In stock
Only 1 remaining
$7.22
You save $1.27
In stock
Only 1 remaining
$35.69
You save $6.30
13
Yamaha Motors
Compression Spring90501-18576-00
Required: 1
SPRING, COMPRESSION
In stock
Only 2 remaining
$8.07
You save $1.42
$16.99
You save $3.00
$7.22
You save $1.27
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
