2002 Cruiser XV1600A - XV1600A (5JAA) [050] GENERATOR diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors XV1600A (5JAA) [050] - GENERATOR
Change View:
Alternator Stator Assembly
1
Yamaha Motors
Alternator Stator Assembly4WM-81410-01-00
Required: 1
STATOR ASSY
Supersedes: 4WM-81410-00-00
Cross Ship
Leaves in 2-5 days
$642.99
$546.54
You save $96.45
More details
Rotor Assembly
2
Yamaha Motors
Rotor Assembly4WM-81450-00-00
Required: 1
ROTOR ASSY
Cross Ship
Leaves in 2-5 days
$429.99
$365.49
You save $64.50
More details
PICK-UP ASSY
3
Yamaha Motors
PICK-UP ASSY4WM-81670-02-00
Required: 1
PICK-UP ASSY
Supersedes: 4WM-81670-01-00
Cross Ship
Leaves in 2-5 days
$97.99
$83.29
You save $14.70
More details
Pan Head Screw
4
Yamaha Motors
Pan Head Screw98507-06035-00
Required: 3
SCREW, PAN HEAD
Cross Ship
Leaves in 2-5 days
$9.49
$8.07
You save $1.42
More details
PAN HEAD SCREW WITH WASHER
6
Yamaha Motors
PAN HEAD SCREW WITH WASHER97607-06216-00
Required: 2
SCREW, WITH WASHER
Supersedes: 90159-06004-00
Cross Ship
Leaves in 2-5 days
$2.90
$2.46
You save $0.44
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
