2012 ATV YFM700R - YFM700R (1ASH) [010] ELECTRICAL 2 diagram
![Yamaha Motors YFM700R (1ASH) [010] - ELECTRICAL 2](https://cdn.crowleymarine.com/yamaha/1g7gn6ud.png)
1
Yamaha Motors
3Y6-85130-01-003Y6-85130-00-00
Required: 1
REAR REFLECTOR ASSY
Supersedes: 3Y6-85130-02-00
$16.14
You save $2.85
-50%
2
Yamaha Motors
Spring Washer92902-05100-00
Required: 1
WASHER, SPRING
In stock
Only 2 remaining
$0.77
You save $0.77
3
Yamaha Motors
Nut95380-05600-00
Required: 1
NUT
Supersedes: 95302-05600-00
In stock
Only 5 remaining
$7.59
You save $1.90
4
Yamaha Motors
Rear Reflector449-85131-02-00
Required: 2
REFLECTOR, REAR 1
$28.89
You save $5.10
-50%
5
Yamaha Motors
Plain Washer92990-05200-00
Required: 2
WASHER
Supersedes: 92902-05200-00
In stock
Only 1 remaining
$2.50
You save $2.50
-50%
6
Yamaha Motors
Spring Washer92902-05100-00
Required: 2
WASHER, SPRING
In stock
Only 2 remaining
$0.77
You save $0.77
7
Required: 1
BRACKET, REFLECTOR 1
Price unavailable
8
Required: 1
BRACKET, REFLECTOR 2
Price unavailable
9
Yamaha Motors
Reflector - Front2EK-85111-00-00
Required: 2
REFLECTOR, FRONT 1
$27.19
You save $4.80
-50%
10
Yamaha Motors
Plain Washer92990-05200-00
Required: 2
WASHER
Supersedes: 92902-05200-00
In stock
Only 1 remaining
$2.50
You save $2.50
-50%
11
Yamaha Motors
Spring Washer92902-05100-00
Required: 2
WASHER, SPRING
In stock
Only 2 remaining
$0.77
You save $0.77
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
