All diagrams for this model

1989 ATV YFA1 - YFA1 (3FA2) [020] SEAT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Yamaha Motors YFA1 (3FA2) [020] - SEAT
Change View:
SEMI-DBL SEAT ASSY
1
Yamaha Motors
SEMI-DBL SEAT ASSY3FA-24710-00-00
Required: 1
SEMI-DOUBLE SEAT ASSY
Supersedes: 3FA-24770-00-00
Cross Ship
Leaves in 2-5 days
$261.99
$222.69
You save $39.30
More details
Double Seat Cover
2
Yamaha Motors
Double Seat Cover3FA-24731-00-00
Required: 1
.COVER, seat
Cross Ship
Leaves in 2-5 days
$88.99
$75.64
You save $13.35
More details
MAIN STAND STOPPER
3
Yamaha Motors
MAIN STAND STOPPER371-27114-00-00
Required: 3
.STOPPER, main stand
Cross Ship
Leaves in 2-5 days
$8.49
$7.22
You save $1.27
More details
NUT WITH WASHER
4
Yamaha Motors
NUT WITH WASHER95701-06500-00
Required: 2
.NUT, flange
Cross Ship
Leaves in 2-5 days
$2.35
$2.00
You save $0.35
More details
Seat Lever
5
Yamaha Motors
Seat Lever29U-24776-00-00
Required: 1
.LEVER, seat
Cross Ship
Leaves in 2-5 days
$15.49
$13.17
You save $2.32
More details
Seat Lever Bracket
6
Yamaha Motors
Seat Lever Bracket4K0-24775-00-00
Required: 1
.BRACKET, seat lever
Cross Ship
Leaves in 2-5 days
$7.49
$6.37
You save $1.12
More details
PIN
7
Yamaha Motors
PIN4K0-24774-01-00
Required: 1
.PIN
Cross Ship
Leaves in 2-5 days
$17.99
$15.29
You save $2.70
More details
TORSION SPRING
8
Yamaha Motors
TORSION SPRING90508-20779-00
Required: 1
.SPRING, torsion
Cross Ship
Leaves in 2-5 days
$6.49
$5.52
You save $0.97
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
