Serial Range Four-Stroke Outboard 8 - DF8A 710001~ FUEL TANK diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status

Click on

to see part

Ships Now

Ships Later

Out of Stock

Change View:

Required: 1

TANK ASSY, FUEL (12L)

Price unavailable

Suzuki Marine

HOSE,FUEL TANK65700-87J26

Required: 1

HOSE, FUEL

Supersedes: 65700-87J25

~~$240.29~~

$204.25

You save $36.04

More details

Suzuki Marine

SOCKET,FUEL HOS65750-87J11

Required: 1

.SOCKET, FUEL HOSE

In stock

Only 1 remaining

~~$21.68~~

$17.34

You save $4.34

More details

Suzuki Marine

SOCKET,FUEL HOS65750-95501

Required: 1

.SOCKET, FUEL HOSE

Supersedes: 65750-95500

In stock

Only 1 remaining

~~$33.76~~

$27.01

You save $6.75

More details

Suzuki Marine

PUMP COMP,SQUEE65770-90J04

Required: 1

.PUMP, SQUEEZE

Supersedes: 65770-90J02

~~$174.75~~

$148.54

You save $26.21

.CLIP

~~$3.22~~

$2.58

You save $0.64

More details

Suzuki Marine

PLUG,FUEL CONNE65720-986L0

Required: 1

PLUG, FUEL CONNECTOR

~~$59.49~~

$47.59

You save $11.90

BOLT (6X12.5)

~~$4.28~~

$3.42

You save $0.86

WASHER (6.5X15X1)

~~$1.50~~

$1.20

You save $0.30

More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.

Flat $9.95 Shipping on ALL parts orders

Serial Range Four-Stroke Outboard 8 - DF8A 710001~ FUEL TANK diagram
