All diagrams for this model

All Years Lawn Tractor HT - HT3813K1 SA HEADLIGHT diagram

Reference numbers in this diagram are listed below — scroll down to order. ALL PARTS LISTED ARE GENUINE OEM.

Drag the image to move around or use the controls below. 🖨 Print this page

Product availability is updated on this page every 24 hours. Add an item to the shopping cart to view its current status
Click on
9
to see part
9
Ships Now
9
Ships Later
9
Out of Stock
Honda HT3813K1 SA - HEADLIGHT
Change View:
001
Required: 1
HEADLIGHT ASSY.
N
Price unavailable
001
Required: 1
HEADLIGHT ASSY.
N
Price unavailable
002
Required: 1
HEADLIGHT UNIT (NOT AVAILABLE)
N
Price unavailable
SOCKET, HEADLIGHT
003
Honda
SOCKET, HEADLIGHT33130-750-003
Required: 1
SOCKET, HEADLIGHT
N
Cross Ship
Leaves in 2-5 days
$54.16
$46.04
You save $8.12
More details
BULB (12V 15W)
004
Honda
BULB (12V 15W)34901-GK8-702
Required: 2
BULB, HEADLIGHT (12V 15W)
N
Cross Ship
Leaves in 2-5 days
$6.14
$5.22
You save $0.92
More details
COLLAR, COWL SETTING
005
Honda
COLLAR, COWL SETTING90122-463-770
Required: 2
COLLAR, COWL SETTING (LOWER)
N
Cross Ship
Leaves in 2-5 days
$5.90
$5.02
You save $0.88
More details
BOLT, FLANGE (6X16)
007
Honda
BOLT, FLANGE (6X16)95701-06016-08
Required: 3
BOLT, FLANGE (6X16)
N
Cross Ship
Leaves in 2-5 days
$1.82
$1.55
You save $0.27
More details

Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
