All Years Generator EL - EL5000 A THERMOSTAT CASE (1) diagram
001
Honda
WEIGHT, GOVERNOR16511-ZA0-010
Required: 2
WEIGHT, GOVERNOR
N
$6.09
You save $1.07
002
Required: 1
HOLDER, GOVERNOR WEIGHT
N
Price unavailable
002
Required: 1
HOLDER, GOVERNOR WEIGHT
N
Price unavailable
003
Honda
PIN, GOVERNOR WEIGHT16513-ZA0-300
Required: 2
PIN, GOVERNOR WEIGHT
N
$1.43
You save $0.25
004
Honda
GEAR, GOVERNOR DRIVE16515-ZA0-003
Required: 1
GEAR, GOVERNOR DRIVE
N
$11.37
You save $2.01
005
Required: 1
SLIDER, GOVERNOR
N
Price unavailable
006
Required: 1
SHAFT, GOVERNOR ARM (NOT AVAILABLE)
N
Price unavailable
007
Required: 1
FORK, GOVERNOR (NOT AVAILABLE)
N
Price unavailable
008
Required: 1
ARM, GOVERNOR (NOT AVAILABLE)
N
Price unavailable
009
Required: 1
ROD, GOVERNOR ARM (NOT AVAILABLE)
N
Price unavailable
010
Required: 1
CASE, GOVERNOR (NOT AVAILABLE)
N
Price unavailable
011
Required: 1
SPRING, THROTTLE RETURN (NOT AVAILABLE)
N
Price unavailable
012
Required: 1
GASKET, GOVERNOR CASE
N
Price unavailable
012
Honda
GSKT, GOVERNOR CASE16563-ZA0-800
Required: 1
GASKET, GOVERNOR CASE
N
$7.31
You save $1.29
013
Required: 1
THERMOSTAT ASSY.
N
Price unavailable
013
Honda
THERMOSTAT ASSY.19310-ZA0-701
Required: 1
THERMOSTAT ASSY.
N
$52.72
You save $13.18
014
Required: 1
COVER, THERMOSTAT (NOT AVAILABLE)
N
Price unavailable
015
Required: 1
GASKET, THERMOSTAT COVER (NOT AVAILABLE)
N
Price unavailable
015
Required: 1
GASKET, THERMOSTAT COVER (NOT AVAILABLE)
N
Price unavailable
016
Honda
HOSE, WATER BYPASS19508-ZA0-000
Required: 1
HOSE, WATER BYPASS
N
$7.24
You save $1.28
017
Honda
BOLT, BREATHING19516-PC1-000
Required: 1
BOLT, BREATHING
N
$21.76
You save $3.84
019
Required: 2
BOLT, STUD (6X75) (NOT AVAILABLE)
N
Price unavailable
020
Honda
WASHER, THRUST (6MM)90451-ZE1-000
Required: 2
WASHER, THRUST (6MM)
N
$1.63
You save $0.29
021
Required: 1
WASHER, PLAIN (6MM) (NOT AVAILABLE)
N
Price unavailable
022
Honda
CLIP90602-896-000
Required: 1
CLIP, GOVERNOR HOLDER
N
$1.43
You save $0.25
022
Honda
CLIP90602-ZE1-000
Required: 1
CLIP, GOVERNOR HOLDER
N
$1.34
You save $0.34
023
Honda
OIL SEAL (6X11X4)91231-891-003
Required: 1
OIL SEAL (6X11X4) (ARAI)
N
$2.41
You save $0.43
025
Honda
BOLT, HEX. (6X22)92101-06022-0H
Required: 1
BOLT, HEX. (6X22)
N
$1.67
You save $0.29
026
Honda
SCREW, PAN (3X6)93500-03006-0H
Required: 2
SCREW, PAN (3X6)
N
$0.85
You save $0.15
-50%
027
Honda
NUT, FLANGE (6MM)94050-06080
Required: 3
NUT, FLANGE (6MM)
N
In stock
Only 5 remaining
$0.41
You save $0.41
028
Honda
WASHER, PLAIN (6MM)94101-06800
Required: 2
WASHER, PLAIN (6MM)
N
$0.64
You save $0.16
029
Honda
CLIP, TUBE (A13)95002-01130
Required: 2
CLIP, TUBE (A13)
N
$5.20
You save $0.92
030
Honda
BOLT, FLANGE (6X28)95701-06028-08
Required: 1
BOLT, FLANGE (6X28)
N
$2.26
You save $0.40
031
Honda
BOLT, FLANGE (6X60)95701-06060-08
Required: 2
BOLT, FLANGE (6X60)
N
$2.24
You save $0.40
032
Honda
BOLT, FLANGE (6X22)95701-06022-00
Required: 1
BOLT, FLANGE (6X22)
N
$1.87
You save $0.33
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
