All Years Generator E - E300K3 A EK3 ALTERNATOR diagram
001
Required: 1
FAN, ALTERNATOR COOLING (NOT AVAILABLE)
N
Price unavailable
002
Required: 1
COVER, ALTERNATOR FAN (NOT AVAILABLE)
N
Price unavailable
003
Honda
POINTS ASSY.30202-884-004
Required: 1
POINTS ASSY.
N
$18.17
You save $3.21
004
Required: 1
COVER ASSY., POINTS (NOT AVAILABLE)
N
Price unavailable
005
Required: 1
GASKET, POINTS COVER (NOT AVAILABLE)
N
Price unavailable
006
Honda
CONDENSER, IGNITION30250-884-004
Required: 1
CONDENSER ASSY., IGNITION
N
$21.45
You save $3.79
007
Required: 1
COIL ASSY., IGNITION (NOT AVAILABLE)
N
Price unavailable
008
Required: 1
COLLAR A, IGNITION DISTANCE (NOT AVAILABLE)
N
Price unavailable
009
Required: 1
COLLAR B, IGNITION DISTANCE (NOT AVAILABLE)
N
Price unavailable
010
Required: 1
TERMINAL ASSY., IGNITION (NOT AVAILABLE)
N
Price unavailable
011
Required: 1
BRACKET, RR. (NOT AVAILABLE)
N
Price unavailable
012
Required: 1
STATOR ASSY. (NOT AVAILABLE)
N
Price unavailable
013
Required: 1
ROTOR (NOT AVAILABLE)
N
Price unavailable
014
Required: 1
DIODE ASSY. (NOT AVAILABLE)
N
Price unavailable
015
Required: 4
DIODE (NOT AVAILABLE)
N
Price unavailable
016
Required: 1
WIRE, GROUND (NOT AVAILABLE)
N
Price unavailable
017
Required: 1
CONNECTOR, POLE (8) (NOT AVAILABLE)
N
Price unavailable
018
Required: 1
CLAMP A, WIRE (NOT AVAILABLE)
N
Price unavailable
019
Required: 1
CLAMP, WIRE (NOT AVAILABLE)
N
Price unavailable
020
Honda
NUT, SPECIAL (14MM)90201-836-000
Required: 1
NUT, SPECIAL (14MM) (NOT AVAILABLE)
N
$2.13
You save $0.38
021
Honda
WASHER90474-704-000
Required: 1
WASHER (6X17)
N
$1.55
You save $0.27
022
Required: 4
BOLT, ALTERNATOR SET (NOT AVAILABLE)
N
Price unavailable
023
Honda
BOLT, HEX. (6X14)92101-06014-0A
Required: 1
BOLT, HEX. (6X14)
N
$1.50
You save $0.26
024
Honda
SCREW, PAN (4X6)93500-04006-0H
Required: 1
SCREW, PAN (4X6)
N
$0.94
You save $0.17
-50%
025
Honda
SCREW, PAN (4X8)93500-04008-0H
Required: 2
SCREW, PAN (4X8)
N
In stock
Only 1 remaining
$0.55
You save $0.55
026
Honda
SCREW, PAN (4X12)93500-04012-0A
Required: 2
SCREW, PAN (4X12)
N
$0.85
You save $0.15
027
Honda
SCREW, PAN (4X14)93500-04014-0H
Required: 3
SCREW, PAN (4X14)
N
$0.85
You save $0.15
028
Honda
SCREW, PAN (5X8)93500-05008-0H
Required: 2
SCREW, PAN (5X8)
N
$0.94
You save $0.17
029
Honda
SCREW, PAN (5X8)93500-05008-3J
Required: 1
SCREW, PAN (5X8)
N
$0.97
You save $0.17
030
Honda
SCREW, PAN (5X10)93500-05010-0A
Required: 1
SCREW, PAN (5X10)
N
$0.94
You save $0.17
031
Required: 2
SCREW, PAN (5X55) (NOT AVAILABLE)
N
Price unavailable
032
Honda
WASHER, PLAIN (4MM)94101-04000
Required: 2
WASHER, PLAIN (4MM)
N
$1.02
You save $0.18
033
Honda
WASHER, PLAIN (14MM)94102-14000
Required: 1
WASHER, PLAIN (14MM)
N
$0.68
You save $0.12
034
Honda
WASHER, SPRING (4MM)94111-04000
Required: 3
WASHER, SPRING (4MM)
N
$1.10
You save $0.20
035
Honda
WASHER, SPRING (5MM)94111-05000
Required: 1
WASHER, SPRING (5MM)
N
$1.17
You save $0.21
036
Honda
BEARING (6001UU)96150-60010-10
Required: 6
BEARING, RADIAL BALL (6001UU)
N
$24.92
You save $4.40
Required quantity shown is the quantity used per assembly. Prices are based on a quantity of one and all items are sold individually.
